NCM Powder Lithium Battery Cathode Material Lithium Nickel Manganese Cobalt Oxide

Nickel Manganese Cobalt Oxide NMC=1:1:1 Powder

Product Name:	LiNiMnCoO2	Type:	TMAX-NMC-111
SPECIFICATIONS
Item	Standard	Test result	The analytical methods and instruments
Element content (wt%)
Ni+Mn+Cu	≧58	58.79	Consult GB/T1287-94.GB/T15899-1995.HG/T2631-2005:  Volumetry
Li	7~8	7.29	Consult JY/T 015-1996: Inductively coupled plasma atomic emission spectrometry
Na	≦0.03	0.0036
Fe	≦0.01	0.0032
Cu	≦0.005	0.0001
H2O	≦0.05	0.01875	Consult.GB/T606-2003      C30 Carle Fischer coulometric instrument
Distribution of grain size(um)
d10	≧5	6.66	Consult.GB/T19077.1-2008     Mastersizer2000 laser particle analyzer
d50	8~14	10.11
d90	≦25	20.69
Electrochemical performance
First discharge efficiency(%)	≧85	87	Consult GB/T20252-2006 Appendix C Button half cell 0.2C  4.2v-2.7v
First discharge capacity(mAh/g)	≧153	154.1~154.8
Physical property
BET (m2/g)	0.2~0.5	0.33	Consult GBT 13390-200Tristar specific surface area
TD (g/cm3)	≧2.3	2.5	Consult GB/T5162-2006/ISO3953:1993; FZS4-4B Jolt density meter
PH	≦11.5	11.18	Consult GB/T1717-1986:DELTA320Ph
