Substrate size

5mm to 120mm（ 5 inches）

Plate holder type

Specially designed plate holder to prevent glue from entering

Speed range

50rpm to 10000rpm

Spin time

0s to 999s

Dual LED digital display

1.  Speed display 2.  Countdown time display.

Control method

Set speed and time with the keypad

Motor speed stability

±1RPM

Spin coating uniformity

±1%

Operating voltage (Spin Coater)

AC100-250V, single phase, 50/60Hz

Operating voltage(Pump)

AC220V(Standard)    AC110V(Optional)

Pumping speed

≥60L/MIN

Max vacuum

-85KPA

Sound Level

≤55db

Spin coater power

200W

Pump power

180W

Dimensions(Spin Coater)

210mm(W)X220mm(D)X160mm(H)

Dimensions (Pump)

185 x 100 x 210 mm (L x W x H)

Weight(Spin Coater)

10KG

Weight(Pump)

4.5KG

Relative humidity

< 85%

Ambient temperature

0-40℃

Warranty

1 year
