Model

TMAX-1700

Muffle-I

TMAX-1700

Muffle- II

TMAX-1700Muffle- III

TMAX-1700Muffle-Ⅳ

TMAX-1700Muffle-Ⅴ

TMAX-1700Muffle-ⅤI

TMAX-1700Muffle-vI I

Power

2.5 KW

3 KW

5 KW

7KW

9 KW

13KW

24KW

Chamber size（DXWXH）

120X120

X120mm

160X150

X150mm

200X200

X200mm

300X200

X200mm

300X250

X250mm

400X300

X300mm

500X400

X400mm

470*480

*820

520X490

X880

564X530

X930

600X630

X970

620X630

X1020

670X760

X1450

840X870

X1740

Supply voltage

220V

220V

220V

220V

380V

380V

380V

Phase

                         single phase

Heating element

        1800TypeMoSi2 heating element

Control mode

UAV program temperature control instrument

1, 30-stage program temperature control intelligent PID adjustment.

2. With over-temperature protection, the electric furnace heating circuit is automatically cut off when the temperature is over-temperature or broken, (when the electric furnace temperature exceeds 1720 degrees or the thermocouple is blown, the AC relay on the main circuit will be automatically disconnected, the main circuit is broken. On, the ON light on the panel is off, the OFF light is on, and the limited protection electric furnace).

3, with 485 communication interface (standard when purchasing software)

4, with power-off protection function, that is, when the power is turned on after the power is turned off, the program does not start from the starting temperature, but the furnace temperature rises from the time of power failure.

5. The meter has the function of temperature self-tuning.

Heating rate

                                 ≤30℃/ Min

Recommended rate

                                  15℃/ Min

Chamber material

Type 1800 alumina polycrystalline fiber (alumina content above 95%)

Control precision

                                  +/- 1℃

max temperature

                                  1700℃

rated temperature

                                  1650℃

Peripheral surface temperature

                                    ≤45℃

Thermocouple Type

                                        B

Trigger

Phase shift trigger (with soft start and current limit function)

Current limiting function: No matter how to adjust the heating time, the secondary current of our electric furnace after passing through the transformer is limited to 160A, which has limited protection of the equipment, no matter how you operate, it will not burn out the equipment.

Soft start function: the current will increase slowly when starting up, and the impact on the heating element is small, which is beneficial to the extension of the life of the heating element.

electric appliance

                           Zhejiang chint

silicon controlled

                       106/16E SEMIKRON

Travel switch

A travel switch is installed on the furnace door. When the furnace door is opened, the power supply is automatically cut off to prevent the electric shock from being caught when the heating element is hit.
