Item NO.:
TMAX-T-PVDFPayment:
L/C,T/T,Western Union, PaypalLead Time:
2 daysCertificate:
CE ROHS Certificate
Application: Binder for lithium ion battery positive
electrode active material, generally mixed with NMP solvent
Appearance: White powder
Usage:
761A is a kind of powder - like polyvinyl fluoride product, which has good
solubility in some solvents.
Compared with other brands of 761A, PVDF is more suitable as a lithium battery
electrode binder material, less than similar products, thereby increasing the
capacity of the battery.
761A is a kind of polymer material with high dielectric constant, which has
high viscosity and adhesion in a certain solvent.
The lithium battery membrane electrode material made of 761A has good chemical
stability, temperature stability and good workability.
Item |
Unit |
Test way |
Stand |
Purity |
% |
/ |
More than 99.9% |
Density |
g/cm3 |
D792 |
1.77-1.80 |
Melting point |
℃ |
D3418 |
165-172 |
molecular weight |
/ |
/ |
65-75 |
(230℃,5kg) / Melt Flow Index |
g/10min |
D3835 |
1-2 |
Characteristic viscosity |
dl/g |
DMA,30℃ |
1.0-2.0 |
Rotary viscometer |
Mpa.s |
1g/10ml NMP,30℃ |
>2500 |
solubility |
/ |
NMP/DMP,30℃,1hr |
clear solution |
Shao Hardness |
D |
D2240 |
76-80 |
shrinking percentage |
% |
D955 |
2.0-3.0 |
Water absorption |
% |
D570 |
0.01-0.03 |
Thermal decomposition (1% Wt loos in air) |
℃ |
TGA |
370-390 |
