Name

Qty

DPH-1000ZD3-CW-CX- W-533

DPH-1500ZD3-CW-

CX-W-533

DPH-2000ZD3-CW-CX- W-533

DPH-3000ZD3-

CW-CX- W-533

Laser (W)

1 set

TMAX1000

TMAX1500

TMAX2000

TMAX3000

Cooling-Water Machine

1 set

HL-1000

HL-1500

HL-2000

HL-3000

Welding Head

(Including CCD +

Monitor)

1 set

ND26/ND15(Optional)

ND26/ND15(Optional)

ND26/ND24(Optional)

ND40/ND24(Optional)

XYZ Axis Stroke mm

(Stroke can be customized)

1 set

500*300*300

500*300*300

500*300*300

500*300*300

Control System (Optional)

1 set

C6L Four Axis/C6S Six  Axis

C6L Four Axis/C6S Six  Axis

C6L Four Axis/C6S Six  Axis

C6L Four Axis/C6S Six Axis

Industrial Computer

1 set

PCI Computer keyboard and mouse with display

Servo (XY Axis)

2 sets

Panasonic 400W large inertia (including driver), 1 set of XY

Servo (Z Axis)

1 set

Panasonic 400W large inertia belt brake (including driver)
