Features

Adjustable temperature control

Adjustable pressure control

Working Voltage

AC220V±10% 50/60Hz

Working Pressure

0~900Kg ±3Kg

Working Distance

0-80mm

Working Temperature

Upper and Lower Platen:130ºC±5ºC Max.

Hot pressing area

200 x 200 mm/300 x 300mm/400 x 400mm optional

Short Circuit

Auto alarm

Testing Input Voltage

DC 0~500V adjustable

Max. Measurable Leakage Current

50 uA

Resistivity Measurement Range

Max. 199MΩ

Testing Period

0~99 Seconds adjustable (2~3 seconds is suggested)

Air Pressure

0.1Mpa~0.7Mpa is suggested.

Yields

<600pcs/hour

Warranty

One year limited manufacturer's warranty with lifetime support; extended warranty available upon request at additional cost.

Dimensions

500L×500W×1025H mm

Weight

220KG
