Specifications

MODEL	Conductive agent content	Dispersant content	Stabilizer Content	D50 (μm)	Viscosity (mPa.s)
TMAX-KNG -LB102-1	5% graphene	0.25%	0	9	10000
TMAX-KNG -LB102-2	5% graphene	0.25%	1.5%	9	8000
TMAX-KNG -LB102-3	4.3% Composite materials	0.25%	1.5%	9	6000

Impurity content

Testing  Products	Iron  content	Molybdenum  content	Chromium  content	Calcium  content	Copper  conten	Sulfur content
Graphene slurry	<10ppm	<0.1ppm	<0.1ppm	<10ppm	<0.1ppm	<100ppm

Recommended dosage

Electrode active material type	Improve capacity purpose	Enhanced magnification purpose
LFP	0.5-1.5%	1.0-2.0%
LCO	0.5-1.0%	1.0-2.0%
NCM	0.5-1.5%	1.0-2.0%

Recommendation: Graphene and carbon nanotubes or with the use of conductive carbon black
