Type

1200-I

1200-II

1200-III

1200-V

1200-VI

1200-VII

Power

3.5KW

3.5KW

3.5KW

5KW

6KW

7KW

Tube size（OD(mm)

Dia 60 X1000

 Dia80X1000

Dia100X1000

Dia150X1000

Dia200X1000

Dia250X1000

Dimensions

1140X450X690

1140X450X690

1140X450X690

1110X530X755

1120X580X805

1314X680X905

Supply voltage

                                             220V

Phase

                                      Single phase

Heating element

                                      Resistance wire

Temperature control

UAV program temperature control instrument (standard)

1, 30-stage program temperature control intelligent PID adjustment.

2. With over-temperature protection, the electric furnace heating circuit is automatically cut off when the temperature is over-temperature or broken, (when the electric furnace temperature exceeds 1200 degrees or the thermocouple is blown, the AC relay on the main circuit will be automatically disconnected, the main circuit is broken. On, the ON light on the panel is off, the OFF light is on, and the limited protection electric furnace).

3, with 485 communication interface (standard when purchasing software)

4, with power-off protection function, that is, when the power is turned on after the power is turned off, the program does not start from the starting temperature, but the furnace temperature rises from the time of power failure.

5, the meter has the function of temperature self-tuning

(you need to pay extra for the replacement of imported instruments, optional)

 FP93 temperature controller (shimashima, Japan)   EUROPEAN instrument   Touch screen instrument

Chamber material

1. High-quality high-purity alumina polycrystalline fiber curing furnace formed by vacuum suction filtration.

2. Formed by Japanese technology.

3. The spacing and pitch of the resistance wires in the furnace are all arranged according to the best thermal technology in Japan, and the temperature field is simulated by the thermal software.

Valve and flange

60/80/100top view

Temperature calibration (optional)

Regular temperature calibration of the tube furnace maintains the accuracy and uniformity of the furnace temperature. You can purchase a simple calibration tool from the company to assist you with this work. The complete calibration kit includes a standard thermocouple S-type, temperature calibrator.

Control accuracy

                                                +/- 1℃

Trigger

                                  Phase-shifted trigger

Electric appliance

                                            Zhejiang chint

Silicon controlled

                                   106/16ESEMIKRON

Maximum temperature

                                            1200℃

Rated temperature

                                               1150℃

Heating rate

               ≤30℃/ Min(it can be modified as required)

Recommended rate of temperature rise

                                           ≤15 ℃/ Min

Thermocouple Type

                                          K Type

Heating length

                                            400-440mm

Constant temperature length

                                               150mm

Temperature field curve

Peripheral surface temperature

                                                  ≤45℃

Open cover protection system

When the furnace cover is opened, the relay will automatically cut off the main power supply, effectively ensuring the safety of the user.
