CR2032 CR2016 CR2025 Coin Cell Case Spring and Spacer for Coin Cell Research

Packing: 100pcs /bag

Model	Diameter / mm	Thickness / mm
2016	20	1.6
2025	20	2.5
2032	20	3.2

Coin Cell Spring

Packing: 100pcs /bag

Specifications
Dimensions (Dia x Height)	15.4mm dia*1.2mm height*0.25mm thickness
Weight	Weight: 0.1 Oz

Coin Cell Spcaer

Packing: 100pcs /bag

Specifications
Dimensions (Dia x Height)	15.5 mm diameter x 0.2 mm thickness
Weight	0.1 Oz

Other coin cell type:

Name	Model/Size	Material
Coin cell case	CR2032	304ss/316ss/Gold-Coated/Al-Coated/ Kapton
	CR2016	304ss/316ss/ Kapton
	CR2025	304ss/316ss
	CR2450	304ss
	CR2430	304ss/316ss
	CR2325	304ss
	CR1620	304ss
	CR1632	T:3.2mm D:16mm  304ss
	CR1616	304ss
	CR1220	304ss
	CR1820	304ss
	CR0927	304ss
	CR1220	304SS
	CR1025	304SS
	CR1016	304SS
	CR3048	304SS
	CR3032	304SS
	CR2477	304ss
	CR2032 Lithium air case	304ss
Coin cell spacer	15.8*0.2mm	304ss/316ss
	15.8*0.5mm	304ss/316ss/Pure aluminum
	15.8*0.8mm	304ss/316ss
	15.8*1mm	304ss/316ss
	20.2*0.4mm	304ss
Wave Spring (Belleville Washers)	15.4O.D*10.5 I.D*1.0Height*0.25 Thickness mm	304ss/316ss
Coin Cell Conical Spring	15.4 mm dia * 1.1 mm height *0.25 mm thickness	304ss/316ss
	20*1.7mm	304ss
