Power Supply

Standard 220 V AC  50 Hz.

Power

400 W

Inner Chamber size

300 mm x 300 mm x 275mm    ( 12 x 12 x 11",  25 Liter )

Outside size

605mm x 490mm x 450mm(without vacuum pump)

Vacuum

< 133pa

Shipping size

650mm x 550mm x 500mm

Shipping weight

170 Lbs

Model

DZF-6020

DZF-6050

DZF-6090

DZF-6090

Working Room Size(mm)

300*300*275

415*370*345

450*450*450

560*600*640

Overall Size(mm)

605*490*450

710*560*550

610*660*1400

720*820*1750

Loading Shelf/Bracket

1 layer

2 layer

2 layer

3 layer

Temperature range

RT+10~250 C

Temperature resolution

±0.1°C

Constant temperature volatility

±1°C

Achieved vacuum degree(pa)

-133

Time range

1~9999M

Total power

450W/1450W/1400W/2200W

Power supply requirements

AC220V ± 10% 50 ± 0.5HZ (Single-phase three-wire system)

AC220V ± 10% 50 ± 0.5HZ (Single-phase three-wire system)
